Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 37
Error Code
Item
Description
11-01
11-02
Remedy
[Related parts]
• Ink Ribbon Cassette
• Harnesses from the Ribbon Feed Length Sensor (Wind Up Axis) (SN10
)
to the Main board
• Harnesses from the Ribbon Wind Up Motor (DM1) to the Main board
• Ribbon Feed Length Sensor (Wind Up Axis) (SN10)
• Ribbon Wind Up Motor (DM1)
• Main board
[Remedy]
1. Check the following items of the ink ribbon cassette.
⋅
There is no damage in the ink ribbon cassette.
⋅
There is no breakage or improper winding of the ink ribbon.
⋅
It is not empty.
⋅
The ink ribbon is properly set.
2. Check the reaction of the Ribbon Feed Length Sensor (Wind Up Axis)
(SN10) in the sensor check mode of the service mode (page 27
).
3. Check/replace the related harness/cable, connector and parts.
11-03
11-04
Error Message
Ribbon Wind up.
Outline
Ink ribbon wind up speed error (supply axis)
Detection Description
The printer detected the wind-up speed error of the ink ribbon.
Remedy
[Related parts]
• Ink Ribbon Cassette
• Harnesses from the Ribbon Feed Length Sensor (Supply Axis)
(SN11)/Ribbon Supply Motor (DM2) to the Main board
• Ribbon Feed Length Sensor (Supply Axis) (SN11)/Ribbon Supply Motor
(DM2)
• Main board
[Remedy]
1. Check the following items of the ink ribbon cassette.
⋅
There is no damage in the ink ribbon cassette.
⋅
There is no breakage or improper winding of the ink ribbon.
⋅
It is not empty.
⋅
The ink ribbon is properly set.
2. Check the reaction of the Ribbon Feed Length Sensor (Supply Axis)
(SN11) in the sensor check mode of the service mode (page 27
).
3. Check/replace the related harness/cable, connector and parts.
12-XX
Error Message
Invalid Ribbon
Outline
Ink ribbon feed operation timeout error
Detection Description
The printer detected the feed operation timeout of the ink ribbon.
Remedy
[Related parts]
• Ink Ribbon Cassette
• Harnesses from the Ribbon Beginning Sensor (SN9
) to the Main
board
• Ribbon Beginning Sensor (SN9)
• Main board
[Remedy]
1. Check the following items of the ink ribbon cassette.
⋅
There is no damage in the ink ribbon cassette.
⋅
There is no breakage or improper winding of the ink ribbon.
⋅
It is not empty.
⋅
The ink ribbon is properly set.
2. Execute the sensor automatic adjustment in the sensor check mode
of the service mode (page 27).
3. Check/replace the related harness/cable, connector and parts.
13-01
13-02
13-03
Error Message
Invalid Ribbon
Outline
Ink ribbon panel interval error (short)
Detection Description
The printer detected the panel interval error (short) of the ink ribbon.

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
