Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 39
Error Code
Item
Description
13-09
Remedy
[Related parts]
• Ink Ribbon Cassette
• Harnesses from the Ribbon Beginning Sensor (SN9
) to the Main
board
• Ribbon Beginning Sensor (SN9)
• Main board
[Remedy]
1. Check the following items of the ink ribbon cassette.
⋅
There is no damage in the ink ribbon cassette.
⋅
There is no breakage or improper winding of the ink ribbon.
⋅
It is not empty.
⋅
The ink ribbon is properly set.
2. Execute the sensor automatic adjustment in the sensor check mode
of the service mode (page 27).
3. Check/replace the related harness/cable, connector and parts.
13-0A
Error Message
Invalid Ribbon
Outline
Ink ribbon empty mark error
Detection Description
The printer detected the empty mark of the ink ribbon.
Remedy
[Related parts]
• Ink Ribbon Cassette
• ID-key
• Harnesses from the Ribbon Beginning Sensor (SN9
) to the Main
board
• Ribbon Beginning Sensor (SN9)
• Main board
[Remedy]
1. Check the following items of the ink ribbon cassette.
⋅
There is no damage in the ink ribbon cassette.
⋅
There is no breakage or improper winding of the ink ribbon.
⋅
It is not empty.
⋅
The ink ribbon is properly set.
2. Make sure that ID-key and the type of the set ink ribbon are identical.
3. Execute the sensor automatic adjustment in the sensor check mode
of the service mode (page 27).
4. Check/replace the related harness/cable, connector and parts.
13-0B
Error Message
Invalid Ribbon
Outline
Ink ribbon empty mark error
Detection Description
The printer detected the empty mark of the ink ribbon. (Remaining amount:
More than 5%)
Remedy
[Related parts]
• Ink Ribbon Cassette
• ID-key
• Harnesses from the Ribbon Beginning Sensor (SN9
) to the Main
board
• Ribbon Beginning Sensor (SN9)
• Main board
[Remedy]
1. Check the following items of the ink ribbon cassette.
⋅
There is no damage in the ink ribbon cassette.
⋅
There is no breakage or improper winding of the ink ribbon.
⋅
It is not empty.
⋅
The ink ribbon is properly set.
2. Make sure that ID-key and the type of the set ink ribbon are identical.
3. Execute the sensor automatic adjustment in the sensor check mode
of the service mode (page 27).
4. Check/replace the related harness/cable, connector and parts.
14-XX
Error Message
Invalid Ribbon
Outline
Ink ribbon type error
Detection Description
The printer detected a different type of ribbon than the set ink ribbon.

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
