976 FTBx-88000 Series
Grand Master Information / Boundary Clock Information
For G.8265.1, G.8275.1 and G.8275.2:
Clock Class reports the description and code of the Grand Master
Clock Class.
Clock Mode reports the description of the Grand Master Clock Mode:
Two-step or One-step.
Clock Accuracy reports the accuracy of the clock.
Time Source reports the source of time used by the Grand Master
Clock.
Code Description
0-5, 8-12, 15-51, 53-57, 59-67, 123-132, 171-186, 188-192, 194-215,
233-247, 249-254
Reserved
6 Sync to primary reference
7, 14 Holdover
13 Sync to application-specific reference
52, 58, 187, 193 Degraded
68 to 79, 81-109 (odd values), 11-122, 133-170, 216-232 Alternate PTP profiles
80-110 (even values)
a
a. Refer to QL table on page 216 for the list of Quality Level values that will be used as the description.
Quality Level (QL-xxx
a
)
248 Default
255 Slave only
