Configuring Quality of Service
December 2005 © Foundry Networks, Inc. 13 - 5
Table 13.2: Default QoS Mappings, Columns 0 to 15
DSCP value
0123456789101112121415
802.1p
(COS) Value
0000000011111111
DSCP value
0123456789101112121415
Internal
Forwarding
Priority
0000000011111111
Forwarding
Queue
0000000011111111
Table 13.3: Default QoS Mappings, Columns 16 to 31
DSCP value
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
802.1p
(COS) Value
2222222233333333
DSCP value
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Internal
Forwarding
Priority
2222222233333333
Forwarding
Queue
2222222233333333
Table 13.4: Default QoS Mappings, Columns 32 to 47
DSCP value
32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47
802.1p
(COS) Value
4444444455555555
DSCP value 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47
Internal
Forwarding
Priority
4444444455555555
Forwarding
Queue
4444444455555555
