Foundry Networks FESX User Manual

Traffic Policies
December 2005 © Foundry Networks, Inc. 15 11
Table 3: Traffic Policy Information
This Line... Displays...
Traffic Policy The name of the traffic policy.
Metering Shows whether or not rate limiting was configured as part of
the traffic policy.
• Enabled – The traffic policy includes a rate limiting
configuration.
• Disabled – The traffic policy does not include a rate
limiting configuration
Mode If rate limiting is enabled, this field shows the type of
metering enabled on the port:
• Fixed Rate-Limiting
• Adaptive Rate-Limiting
cir The committed information rate, in kbps, for the adaptive
rate-limiting policy.
cbs The committed burst size, in bytes per second, for the
adaptive rate-limiting policy.
pir The peak information rate, in kbps, for the adaptive rate-
limiting policy.
pbs The peak burst size, in bytes per second, for the adaptive
rate-limiting policy.
Counting Shows whether or not ACL counting was configured as part
of the traffic policy.
• Enabled – The traffic policy includes an ACL counting
configuration.
• Disabled – The traffic policy does not include an ACL
traffic counting configuration.
Number of References/
Bindings
The number of times this traffic policy is referenced in an
ACL statement and the number of active bindings for this
traffic policy.
