Foundry Configuration Guide for the FESX, FSX, and FWSX
16 - 76 © Foundry Networks, Inc. December 2005
Displaying IP Traffic Statistics
To display IP traffic statistics on a Layer 2 Switch, enter the following command at any CLI level:
Syntax: show ip traffic
The show ip traffic command displays the following information.
VlanId The VLAN the port that learned the entry is in.
Note: If the MAC address is all zeros, this field shows a random
VLAN ID, since the Layer 2 Switch does not yet know which port the
device for this entry is attached to.
Total ARP Entries The number of entries in the ARP cache.
Table 16.17: CLI Display of IP Traffic Statistics – Layer 2 Switch
This Field... Displays...
IP statistics
received The total number of IP packets received by the device.
Table 16.16: CLI Display of ARP Cache (Continued)
This Field... Displays...
FESX424 Switch# show ip traffic
IP Statistics
27 received, 24 sent
0 fragmented, 0 reassembled, 0 bad header
0 no route, 0 unknown proto, 0 no buffer, 0 other errors
ICMP Statistics
Received:
0 total, 0 errors, 0 unreachable, 0 time exceed
0 parameter, 0 source quench, 0 redirect, 0 echo,
0 echo reply, 0 timestamp, 0 timestamp rely, 0 addr mask
0 addr mask reply, 0 irdp advertisement, 0 irdp solicitation
Sent:
0 total, 0 errors, 0 unreachable, 0 time exceed
0 parameter, 0 source quench, 0 redirect, 0 echo,
0 echo reply, 0 timestamp, 0 timestamp rely, 0 addr mask
0 addr mask reply, 0 irdp advertisement, 0 irdp solicitation
UDP Statistics
0 received, 0 sent, 0 no port, 0 input errors
TCP Statistics
1 current active tcbs, 4 tcbs allocated, 0 tcbs freed 0 tcbs protected
0 active opens, 0 passive opens, 0 failed attempts
0 active resets, 0 passive resets, 0 input errors
27 in segments, 24 out segments, 0 retransmission
