Configuring IP Multicast Traffic Reduction
December 2005 © Foundry Networks, Inc. 18 - 15
This display shows the following information.
Displaying PIM SM Snooping Information for a Specific Source in a Group
You can display PIM SM snooping information for a specific (source, group) pair by entering commands such as
the following at any level of the CLI:
Syntax: show ip pimsm-snooping <group-address> <source-ip-address>
The Foundry device determines which address is the group address and which one is the source address based
on the ranges that the address fall into. If the address is within the range of source addresses, then the router
treats it as the source address. Likewise, if the address falls in the range of group addresses, then the router
assumes it is a group address.
The output shows the following information.
This Field... Displays...
VLAN ID The port-based VLAN to which the information listed below apply and
the number of members in the VLAN.
PIM SM Neighbor list The PIM SM routers that are attached to the Layer 2 Switch’s ports in
the VLAN.
The value following “expires” indicates how many seconds the Layer 2
Switch will wait for a hello message from the neighbor before
determining that the neighbor is no longer present and removing the
neighbor from the list.
Multicast Group The IP address of the multicast group.
Note: The fid and camindex values are used by Foundry Technical
Support for troubleshooting.
Forwarding Port The port(s) attached to the group’s receivers. A port is listed here
when it receives a join message for the group, an IGMP membership
report for the group, or both.
PIMv2 Group Port The port(s) on which the Layer 2 Switch has received PIM SM join
messages for the group.
Source, Port list The IP address of each PIM SM source and the Layer 2 Switch ports
connected to the receivers of the source.
This Field... Displays...
VLAN ID VLAN membership of the source
Group Address of the group
Source IP address of the source
Age Age of the source.
FastIron SuperX Switch# show ip pimsm-snooping 239.255.163.2 192.168.176.44
Show pimsm snooping source 192.168.176.44, group 239.255.163.2 in all vlan
VLAN ID 100, G=239.255.163.2, S=192.168.176.44, age=0, port: 3/2
