Configuring IP Multicast Protocols
December 2005 © Foundry Networks, Inc. 19 - 51
Displaying Source Active Cache Information
To display the Source Actives in the MSDP cache, use the following CLI method.
Syntax: show ip msdp sa-cache
This display shows the following information.
IRcvSeq The initial receive sequence number for the session.
RcvNext The next sequence number expected from the neighbor.
RcvWnd The size of the receive window.
TotalRcv The number of sequence numbers received from the neighbor.
RcvQue The number of sequence numbers in the receive queue.
SendQue The number of sequence numbers in the send queue.
Table 19.4: MSDP Source Active Cache
This Field... Displays...
Total Entry The total number of entries the cache can hold.
Used The number of entries the cache currently contains.
Free The number of additional entries for which the cache has room.
Index The cache entry number.
SourceAddr The IP address of the multicast source.
GroupAddr The IP multicast group to which the source is sending information.
RP The RP through which receivers can access the group traffic from the
source
Table 19.3: MSDP Peer Information (Continued)
This Field... Displays...
FastIron SuperX Router(config-msdp-router)# show ip msdp sa-cache
Total Entry 4096, Used 1800 Free 2296
Index SourceAddr GroupAddr Age
1 (100.100.1.254, 232.1.0.95), RP:206.251.17.41, Age:0
2 (100.100.1.254, 237.1.0.98), RP:206.251.17.41, Age:30
3 (100.100.1.254, 234.1.0.48), RP:206.251.17.41, Age:30
4 (100.100.1.254, 239.1.0.51), RP:206.251.17.41, Age:30
5 (100.100.1.254, 234.1.0.154), RP:206.251.17.41, Age:30
6 (100.100.1.254, 236.1.0.1), RP:206.251.17.41, Age:30
7 (100.100.1.254, 231.1.0.104), RP:206.251.17.41, Age:90
8 (100.100.1.254, 239.1.0.157), RP:206.251.17.41, Age:30
9 (100.100.1.254, 236.1.0.107), RP:206.251.17.41, Age:30
10 (100.100.1.254, 233.1.0.57), RP:206.251.17.41, Age:90
