This display shows the following information.
Table 20.5: CLI Display of OSPF Route Information
This Field... Displays...
Index The row number of the entry in the router’s OSPF route table.
Destination The IP address of the route's destination.
Mask The network mask for the route.
Path_Cost The cost of this route path. (A route can have multiple paths. Each
path represents a different exit port for the Layer 3 Switch.)
Type2_Cost The type 2 cost of this path.
Path_Type The type of path, which can be one of the following:
• Inter – The path to the destination passes into another area.
• Intra – The path to the destination is entirely within the local
area.
• External1 – The path to the destination is a type 1 external
route.
• External2 – The path to the destination is a type 2 external
route.
Adv_Router The OSPF router that advertised the route to this Foundry Layer 3
Switch.
Link-State The link state from which the route was calculated.
Dest_Type The destination type, which can be one of the following:
• ABR – Area Border Router
• ASBR – Autonomous System Boundary Router
• Network – the network
State The route state, which can be one of the following:
• Changed
• Invalid
•Valid
This information is used by Foundry technical support.
Tag The external route tag.
Flags State information for the route entry. This information is used by
Foundry technical support.
Paths The number of paths to the destination.
Out_Port The router port through which the Layer 3 Switch reaches the next
hop for this route path.
Next_Hop The IP address of the next-hop router for this path.
