Foundry Configuration Guide for the FESX, FSX, and FWSX
21 - 66 © Foundry Networks, Inc. December 2005
This display shows the following information.
Table 21.5: BGP4 Summary Information
This Field... Displays...
Router ID The Layer 3 Switch’s router ID.
Local AS Number The BGP4 AS number the router is in.
Confederation Identifier The AS number of the confederation the Layer 3 Switch is in.
Confederation Peers The numbers of the local ASs contained in the confederation. This list
matches the confederation peer list you configure on the Layer 3
Switch.
Maximum Number of Paths
Supported for Load Sharing
The maximum number of route paths across which the device can
balance traffic to the same destination. The feature is enabled by
default but the default number of paths is 1. You can increase the
number from 2 – 4 paths. See “Changing the Maximum Number of
Paths for BGP4 Load Sharing” on page 21-22.
Number of Neighbors Configured The number of BGP4 neighbors configured on this Layer 3 Switch.
Number of Routes Installed The number of BGP4 routes in the router’s BGP4 route table.
To display the BGP4 route table, see “Displaying the BGP4 Route
Table” on page 21-88.
Number of Routes Advertising to All
Neighbors
The total of the RtSent and RtToSend columns for all neighbors.
Number of Attribute Entries Installed The number of BGP4 route-attribute entries in the router’s route-
attributes table. To display the route-attribute table, see “Displaying
BGP4 Route-Attribute Entries” on page 21-96.
Neighbor Address The IP addresses of this router’s BGP4 neighbors.
AS# The AS number.
