Configuring IP Multicast Protocols
December 2000 18 - 33
USING THE WEB MANAGEMENT INTERFACE
You cannot display MSDP information using the Web management interface.
Displaying Peer Information
To display summary MSDP peer information, use the following CLI method.
USING THE CLI
To display MSDP peer information, use the following CLI method.
BigIron(config-msdp-router)# show ip msdp peer
Total number of MSDP Peers: 2
IP Address State
1 206.251.17.30 ESTABLISHED
Keep Alive Time Hold Time
60 90
Message Sent Message Received
Keep Alive 2 3
Notifications 0 0
Source-Active 0 640
Last Connection Reset Reason:Reason Unknown
Notification Message Error Code Received:Unspecified
Notification Message Error SubCode Received:Not Applicable
MSDP Summary Information
This Field... Displays...
Peer Address The IP address of the peer’s interface with the Layer 3 Switch
State The state of the MSDP router’s connection with the peer. The state
can be one of the following:
• CONNECTING – The session is in the active open state.
• ESTABLISHED – The MSDP session is fully up.
• INACTIVE – The session is idle.
• LISTENING – The session is in the passive open state.
KA In The number of MSDP Keepalive messages the MSDP router has
received from the peer
KA Out The number of MSDP Keepalive messages the MSDP router has sent
to the peer
SA In The number of Source Active messages the MSDP router has
received from the peer
SA Out The number of Source Active messages the MSDP router has sent to
the peer
NOT In The number of Notification messages the MSDP router has received
from the peer
NOT Out The number of Notification messages the MSDP router has sent to
the peer
