Foundry Switch and Router Installation and Configuration Guide
22 - 12 December 2000
In preparation for track port configuration on NetIron1, you would do the following:
1. Configure an IP sub-net VLAN with port membership of 1, 2, and 3 on NetIron1.
2. Enable FSRP on virtual interface 1.
3. Assign an IP address to virtual interface 1.
4. Assign ports 1, 2, 3, and 8 as track ports for virtual interface 1.
5. Assign an IP address to interface 8.
6. Assign ports 1, 2, and 3 as track ports for interface 8.
USING THE CLI
To configure the IP sub-net VLAN with port membership of 1, 2, and 3, you would enter the following commands:
NetIron(config)# vlan 1
NetIron(config-vlan-1)# ip-subnet 192.147.200.0 255.255.255.0
NetIron(config-vlan-ip-subnet)# static e1 to 3
NetIron(config-vlan-ip-subnet)# router-int ve1
To enable FSRP on virtual interface 1 and to configure ports 1, 2, 3, and 8 as its track ports, you would enter the
following commands:
NetIron(config)# int ve1
NetIron(config-vif-1)# ip address 192.147.200.1 255.255.255.0
NetIron(config-vif-1)# ip fsrp address 192.147.200.1 vir-rtr 192.147.200.100 other-
rtr 192.147.200.2
NetIron(config-vif-1)# ip fsrp addr 192.147.200.1 track port 1 2 3 8
To enable FSRP on physical interface 8 and to configure ports 1, 2, and 3 as its track ports, you would enter the
following commands:
NetIron(config)# int e8
NetIron(config-if-8)# ip address 192.147.201.1 255.255.255.0
NetIron(config-if-8)# ip fsrp address 192.147.201.1 vir-rtr 192.147.201.100 other-
rtr 192.147.200.2
NetIron(config-if-8)# ip fsrp addr 192.147.201.1 track port 1 2 3
NetIron(config-if-8)# end
NetIron# write memory
NOTE: After configuring track ports for NetIron1, you would configure NetIron2 similarly. This reciprocal
configuration ensures that if NetIron2 becomes the active router, it has track ports that support transfer to a FSRP
standby state.
NOTE: Virtual interfaces cannot be assigned as track ports.
USING THE WEB MANAGEMENT INTERFACE
You can select multiple track ports for FSRP on the FSRP configuration sheet.
