MPC5200B Users Guide, Rev. 1
2-60 Freescale Semiconductor
Pinout Tables
Pin ETH_14 Ball N04
GPIO hi - z INTERRUPT
USB2 hi - z USB_2_RXP
USB Receive Positive
ETH7 Wire hi - z INTERRUPT
ETH7 Wire / USB2 hi - z USB_2_RXP
USB Receive Positive
ETH18 Wire w/o MD hi - z ETH_RXD2
Ethernet Receive Data Input
ETH18 Wire w/ MD hi - z ETH_RXD2
Ethernet Receive Data Input
EHT7 Wire, UART4e, J1850 hi - z UART4e_RXD
Uart Receive Data
ETH7 Wire, J1850 hi - z INTERRUPT
UART_4, UART5e, J1850 hi - z UART4e_RXD
Uart Receive Data
UART5e, J1850 hi - z INTERRUPT
J1850 hi - z INTERRUPT
Pin ETH_15 Ball N03
GPIO hi - z INTERRUPT
USB2 hi - z USB_2_RXN
USB Receive Negative
ETH7 Wire hi - z INTERRUPT
ETH7 Wire / USB2 hi - z USB_2_RXN
USB Receive Negative
ETH18 Wire w/o MD hi - z ETH_RXD3
Ethernet Receive Data Input
ETH18 Wire w/ MD hi - z ETH_RXD3
Ethernet Receive Data Input
EHT7 Wire, UART4e, J1850 hi - z UART4e_CTS
Uart Clear To Send
ETH7 Wire, J1850 hi - z INTERRUPT
UART_4, UART5e, J1850 hi - z UART4e_CTS
Uart Clear To Send
UART5e, J1850 hi - z INTERRUPT
J1850 hi - z INTERRUPT
Table 2-21. Ethernet Input / Control Functions by Pin (continued)
PIN / BALL NUMBER Function
Reset
Value
Description
