9.7.3.5 LPC Rx/Tx FIFO Read Pointer Register—MBAR + 0x3C50
9.7.3.6 LPC Rx/Tx FIFO Write Pointer Register—MBAR + 0x3C54
Table 9-22. LPC Rx/Tx FIFO Read Pointer Register
msb 012345678 9 1011121314 15
R
Reserved
W
RESET:0 00000000 0 0 0 00 0 0
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 lsb
R
Reserved
ReadPtr
W
RESET:0 00000000 0 0 0 00 0 0
Bits Name Description
0:22 — Reserved
23:31 ReadPtr Value is maintained by FIFO hardware and is NOT normally written. It can be adjusted in
special cases, but this disrupts data flow integrity. Value represents the Read address
presented to the FIFO RAM.
Table 9-23. LPC Rx/Tx FIFO Write Pointer Register
msb 012345678 9 1011121314 15
R
Reserved
W
RESET:0 00000000 0 0 0 00 0 0
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 lsb
R
Reserved
WritePtr
W
RESET:0 00000000 0 0 0 00 0 0
Bits Name Description
0:22 — Reserved
23:31 WritePtr Value is maintained by FIFO hardware and is NOT normally written. It can be adjusted in
special cases, but this disrupts data flow integrity. Value represents the Read address
presented to the FIFO RAM.
