7.2.4.3 ICTL Peripheral Priority and HI/LO Select 2 Register —MBAR + 0x0508
7.2.4.4 ICTL Peripheral Priority and HI/LO Select 3 Register —MBAR + 0x050C
Table 7-6. ICTL Peripheral Priority and HI/LO Select 2 Register
msb 012345678 9 101112131415
R Per8_pri Per9_pri Per10_pri Per11_pri
W
RESET:0 00000000 0 0 0 00 0 0
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 lsb
R Per12_pri Per13_pri Per14_pri Per15_pri
W
RESET:0 00000000 0 0 0 00 0 0
Bits Name Description
— Per[x]_pri Identical to Peripheral_Priority 1 Register, but related to peripheral interrupt sources 8
through 15. All bits are programmable and significant.
0:3 Per8_pri Peripheral 8 = PCI Control module
4:7 Per9_pri Peripheral 9 = PCI SC Initiator RX
8:11 Per10_pri Peripheral 10 = PCI SC Initiator TX
12:15 Per11_pri Peripheral 11 = PSC4
16:19 Per12_pri Peripheral 12 = PSC5
20:23 Per13_pri Peripheral 13 = SPI modf
24:27 Per14_pri Peripheral 14 = SPI spif
28:31 Per15_pri Peripheral 15 = I2C1
Table 7-7. ICTL Peripheral Priority and HI/LO Select 3 Register
msb 012345678 9 101112131415
R Per16_pri Per17_pri Per18_pri Per19_pri
W
RESET:0 00000000 0 0 0 00 0 0
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 lsb
R Per20_pri Per21_pri Per22_pri Per23_pri
W
RESET:0 00000000 0 0 0 00 0 0
Bits Name Description
— Per[x]_pri Identical to Peripheral_Priority 2 register, but related to peripheral interrupt sources 16–21.
All bits are programmable and significant.
0:3 Per16_pri Peripheral 16 = I2C2
4:7 Per17_pri Peripheral 17 = CAN1
