7.6.3.2 RTC Date Set Register—MBAR + 0x0804
18:23 Minute_set Minute written in RTC after successful state machine transition by set_time and pause_time
bits.
24:25 — Reserved
26:31 Second_set Second written in RTC after successful state machine transition by set_time and
pause_time bits.
Table 7-57. RTC Date Set Register
msb 012345678 9 101112131415
R
Reserved
set_date
pause_date
Reserved Month_set
W
RESET:0 00000000 0 0 0 00 0 0
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 lsb
R
Reserved Weekday_set Reserved Day_set
W
RESET:0 00000000 0 0 0 00 0 0
Bits Name Description
0:5 — Reserved
6 set_date Operation of pause_date and set_date is similar to pause_time and set_time described in
the time set register.
7 pause_date Used with set_date above to perform date update. Must be zero for normal operation.
8:10 — Reserved
11:15 Month_set New month written in RTC after successful state machine transition by set_date and
pause_date bits. Actually the lower 4 bits is used
16:17 — Reserved
18:23 Weekday_set New weekday written in RTC after state machine transition by set_date and pause_date
bits. 1 = Monday; 7 = Sunday. Actually the lower 3 bits is used.
24:25 — Reserved
26:31 Date_set New date written in RTC after state machine transition by set_date and pause_date bits.
Actually the lower 5 bits is used.
Note: Year_set in the following register is also part of the date set function.
