Freescale Semiconductor MPC5200B - SDMA Task Control C Register-Mbar + 0 X1234; SDMA Task Control E Register-Mbar + 0 X1238

BestComm DMA Registers—MBAR+0x1200
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 13-13
13.15.14 SDMA Task Control C Register—MBAR + 0x1234
SDMA Task Control D Register—MBAR + 0x1236
13.15.15 SDMA Task Control E Register—MBAR + 0x1238
SDMA Task Control F Register—MBAR + 0x123C
Table 13-14. SDMA Task Control C Register
SDMA Task Control D Register
msb 012345678 9 1011121314 15
RTCRC
W
RESET:0 00000000 0 0 0 00 0 0
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 lsb
RTCRD
W
RESET:0 00000000 0 0 0 00 0 0
Bit Name Description
0:15 TCRC Task control register for task 12. Same bit layout as for TCR0
16:31 TCRD Task control register for task 13. Same bit layout as for TCR0
Table 13-15. SDMA Task Control E Register
SDMA Task Control F Register
msb 012345678 9 1011121314 15
R TCRE
W
RESET:0 00000000 0 0 0 00 0 0
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 lsb
R TCRF
W
RESET:0 00000000 0 0 0 00 0 0
Bit Name Description
0:15 TCRE Task control register for task 14. Same bit layout as for TCR0
16:31 TCRF Task control register for task 15. Same bit layout as for TCR0
