Real-Time Clock
7.6.3.8 RTC Periodic Interrupt and Bus Error Register—MBAR + 0x081C
This is a read-only register.
Bits Name Description
0:6 — Reserved
7 Int_alm Status bit indicating that enabled once-a-day Alarm has occurred (active high). Alarm
interrupt has been activated. This bit and the Interrupt is cleared by writing 1 to this bit
position.
Note: A Stopwatch interrupt, if also active, must be cleared before the interrupt signal to the
CPU is negated.
8:14 — Reserved
15 Int_SW Status bit indicating that Stopwatch expiration has occurred (active high). Stopwatch
interrupt has been activated. This bit and the Interrupt are cleared by writing 1 to this bit
position.
Note: An Alarm interrupt, if also active, must be cleared before the interrupt signal to the
CPU is negated.
16:22 — Reserved
23 Alm_status Status bit indicating that once-a-day Alarm has occurred. Same as Int_alm bit above except
that clearing this bit does NOT clear the interrupt.
24:31 SW_min Minutes remaining in stopwatch.
Table 7-63. RTC Periodic Interrupt and Bus Error Register
msb 0123456789101112131415
R
Reserved
Bus_error_1
Reserved
Int_day
W
RESET:0 000000000 0 0000 0
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 lsb
R
Reserved
Int_min
Reserved
Int_sec
W
RESET:0 000000000 0 0000 0
Bits Name Description
0:6 — Reserved
7 Bus_error_1 Internal status register—If high, indicates software has attempted a write access to a
read-only register in this module. No actual register contents are corrupted if this happens.
Cleared by writing 1 to this bit position.
8:14 — Reserved
15 Int_day Periodic interrupt at midnight. High indicates interrupt has occurred.
OR’d function of Int_day, Int_min and Int_sec produces RTC periodic interrupt to CPU
interface.
Cleared by writing 1 to this bit position.
