MPC5200B Users Guide, Rev. 1
13-12 Freescale Semiconductor
BestComm DMA Registers—MBAR+0x1200
13.15.12 SDMA Task Control 8 Register—MBAR + 0x122C
SDMA Task Control 9 Register—MBAR + 0x122E
13.15.13 SDMA Task Control A Register—MBAR + 0x1230
SDMA Task Control B Register—MBAR + 0x1232
Table 13-12. SDMA Task Control 8 Register
SDMA Task Control 9 Register
msb 012345678 9 1011121314 15
RTCR8
W
RESET:0 00000000 0 0 0 00 0 0
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 lsb
RTCR9
W
RESET:0 00000000 0 0 0 00 0 0
Bit Name Description
0:15 TCR8 Task control register for task 8. Same bit layout as for TCR0
16:31 TCR9 Task control register for task 9. Same bit layout as for TCR0
Table 13-13. SDMA Task Control A Register
SDMA Task Control B Register
msb 012345678 9 1011121314 15
R TCRA
W
RESET:0 00000000 0 0 0 00 0 0
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 lsb
R TCRB
W
RESET:0 00000000 0 0 0 00 0 0
Bit Name Description
0:15 TCRA Task control register for task 10. Same bit layout as for TCR0
16:31 TCRB Task control register for task 11. Same bit layout as for TCR0
