Freescale Semiconductor MPC5200B - PSC6 Port Map-4 Pins

Pinout Tables
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 2-65
Figure 2-11. PSC6 Port Map—4 Pins
Pin TIMER_6 Ball E02
TIMER hi - z TIMER_6
GPIO hi - z GPIO
Simple General Purpose I/O
ATA CHIP SELECTS hi - z GPIO
Simple General Purpose I/O
CAN2 hi - z GPIO
Simple General Purpose I/O
SPI hi - z GPIO
Simple General Purpose I/O
CAN2 / SPI hi - z GPIO
Simple General Purpose I/O
Pin TIMER_7 Ball E01
TIMER hi - z TIMER_7
GPIO hi - z GPIO
Simple General Purpose I/O
ATA CHIP SELECTS hi - z GPIO
Simple General Purpose I/O
CAN2 hi - z GPIO
Simple General Purpose I/O
SPI hi - z GPIO
Simple General Purpose I/O
CAN2 / SPI hi - z GPIO
Simple General Purpose I/O
Table 2-23. Timer Functions by Pin (continued)
PIN / BALL NUMBER Function
Reset
Value
Description
GPIO
Pin Drivers and MUX Logic
4
PSC6_0
PSC6_1
PSC6_2
PSC6_3
PSC6
4
Function
Port_conf
[9:11]
PSC6_0 PSC6_1 PSC6_2 PSC6_3
GPIO 000 GPIO_W/WAKE_
UP
GPIO_W/WAKE_UP GPIO GPIO
UART6/
IrDA
101 UART6_RXD/
IrDA_RX
UART6_CTS UART6_TXD/
IrDA_TX
UART6_RTS
CODEC6/
IrDA
111 CODEC6_RXD/
IrDA_RX
CODEC6_FRAME CODEC6_TXD/
IrDA_TX
CODEC6_CLK/
IR_USB_CLK
