Pinout Tables
Pin TIMER_3 Ball D02
TIMER hi - z TIMER_3
GPIO hi - z GPIO
Simple General Purpose I/O
ATA CHIP SELECTS hi - z GPIO
Simple General Purpose I/O
CAN2 hi - z GPIO
Simple General Purpose I/O
SPI hi - z SPI _MISO
SPI Master In Slave Out
CAN2 / SPI hi - z SPI MISO
SPI Master In Slave Out
Pin TIMER_4 Ball D01
TIMER hi - z TIMER_4
GPIO hi - z GPIO
Simple General Purpose I/O
ATA CHIP SELECTS hi - z GPIO
Simple General Purpose I/O
CAN2 hi - z GPIO
Simple General Purpose I/O
SPI hi - z SPI _SS
SPI Slave Select
CAN2 / SPI hi - z SPI SS
SPI Slave Select
Pin TIMER_5 Ball E03
TIMER hi - z TIMER_5
GPIO hi - z GPIO
Simple General Purpose I/O
ATA CHIP SELECTS hi - z GPIO
Simple General Purpose I/O
CAN2 hi - z GPIO
Simple General Purpose I/O
SPI hi - z SPI _CLK
SPI Clock
CAN2 / SPI hi - z SPI CLK
SPI Clock
Table 2-23. Timer Functions by Pin (continued)
PIN / BALL NUMBER Function
Reset
Value
Description
