MPC5200B Users Guide, Rev. 1

13-22 Freescale Semiconductor

BestComm DMA Registers—MBAR+0x1200

13.15.25 SDMA task Size0—MBAR + 0x1260

SDMA task Size 1—MBAR + 0x1264

Table 13-25. FIxed REquestors Table

REQUESTORS Peripheral

REQ15 (RESERVED)

REQ14 PSC1_TX

REQ13 PSC1_RX

REQ12 PSC2_TX

REQ11 PSC2_RX

REQ10 PSC3_TX

REQ9 PSC3_RX

REQ8 PCI TX

REQ7 PCI RX

REQ6 ATA TX

REQ5 ATA RX

REQ4 FEC TX

REQ3 FEC RX

REQ2 (RESERVED)

REQ1 (RESERVED)

REQ0 ALWAYS

Table 13-26. SDMA task Size 0/1

Bits 0,4,8,12,

16,20,24,28

1,5,9,13,

17,21,25,29

2,6,10,14,

18,22,26,30

3,7,1115

19,23,27,31

R srcSize[1] srcSize[0] dstSize[1] dstSize[0]

RESET: At reset all Bits are set to 0
