General Purpose I/O (GPIO)
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 7-45
7.3.2.1.14 GPS GPIO Simple Interrupt Interrupt Types Register —MBAR + 0x0B34
7.3.2.1.15 GPS GPIO Simple Interrupt Master Enable Register —MBAR + 0x0B38
Table 7-34. GPS GPIO Simple Interrupt Interrupt Types Register
msb 012345678 9 101112131415
R ITYP7 ITYP6 ITYP5 ITYP4 ITYP3 ITYP2 ITYP1 ITYP0
W
RESET:0 00000000 0 0 0 00 0 0
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 lsb
R
Reserved
W
RESET:0 00000000 0 0 0 00 0 0
Bit Name Description
0:15 ITYP[0:7] GPIO Interrupt Type bits for Simple-Interrupt GPIO pin 7.
ITYP7—bits 0:1 controls GPIO_SINT_7 (ETH_16 pin)
ITYP6—bits 2:3 controls GPIO_SINT_6 (ETH_15 pin)
ITYP5—bits 4:5 controls GPIO_SINT_5 (ETH_14 pin)
ITYP4—bits 6:7 controls GPIO_SINT_4 (ETH_13 pin)
ITYP3—bits 8:9 controls GPIO_SINT_3 (USB1_9 pin)
ITYP2—bits 10:11 controls GPIO_SINT_2 (PSC3_8 pin)
ITYP1—bits 12:13 controls GPIO_SINT_1 (PSC3_5 pin)
ITYP0—bits 14:15 controls GPIO_SINT_0 (PSC3_4 pin)
00 = Interrupt on any transition
01 = Interrupt on rising edge
10 = Interrupt on falling edge
11 = Interrupt on pulse (any two transitions)
16:31 —
Reserved
Table 7-35. GPS GPIO Simple Interrupt Master Enable Register
msb 012345678 9 101112131415
R
Reserved ME Reserved
W
RESET:0 00000000 0 0 0 00 0 0
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 lsb
R
Reserved
W
RESET:0 00000000 0 0 0 00 0 0
