PSC Registers—MBAR + 0x2000, 0x2200, 0x2400, 0x2600, 0x2800, 0x2C00
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 15-31
3 SHDIR Codec—Shift Direction.
0 = msb first
1 = lsb first
other Modes—Reserved
4:7 SIM[3:0] PSC operation mode.
CAUTION: When the operating mode change occurs, all Rx/Tx and error statuses are reset.
Rx and Tx are disabled.
0000 = UART mode, DCD
input ignored
1000 = UART mode, DCD
input is effective
x001 = Codec mode, 8-bit data
x010 = Codec mode, 16-bit data
x011 = AC97 mode
0100 = SIR model, DCD
input ignored
1100 = SIR mode, DCD
input is effective
x101 = MIR mode
x110 = FIR mode
0111 = Codec mode, 24-bit data
1111 = Codec mode, 32-bit data
8 GenClk Codec—Generate Bit Clock and FrameSync, not used to enable the SPI master mode, use
the MSTR bit of the this register
0 = use bit clock and FrameSync provided by external device
1 = use bit clock and FrameSync generated internally from Mclk
MIR / FIR—Generate Bit Clock and FrameSync
0 = use for clock generation the external Clk from Pad IR_USB_CLK
1 = use for clock generation the internal Mclk
other Modes—Reserved
9I2SCodec—I2S mode
0 = no I2S mode supported
1 = PSC works in I2S mode
other Modes—Reserved
10 ClkPol Codec—Bit Clock Polarity
0 = data in is sampled on the falling edge of the BitClk and data out is shifted on the rising
edge
1 = data in is sampled on the rising edge of the BitClk and data out is shifted on the falling
edge
other Modes—Reserved
11 SyncPol Codec—FrameSync Polarity
0 = FrameSync is low true
1 = FrameSync is high true
Codec I2S—FrameSync Polarity
0 = Frame starts if LRCK is low
1 = Frame starts if LRCK is high
other Modes—Reserved
12 CellSlave Codec—Cell Phone Slave
0 = PSC is not a slave to PSC1
1 = PSC uses Bit Clock from PSC1 master as its Mclk
Bit Name Description
