Freescale Semiconductor MPC5200B - PSC2 Port Map-5 Pins

MPC5200B Users Guide, Rev. 1
2-34 Freescale Semiconductor
Pinout Tables
Figure 2-5. PSC2 Port Map—5 Pins
Table 2-11. PSC2 Pin Functions
Pin
Name
Dir. GPIO CAN1/2 AC97_2 UART2 UART2e CODEC2
CODEC2 w/
MCLK
PSC2_0 I/O GPIO CAN1_TX AC97_2_SDATA_OUT UART2_TXD UART2e_TXD CODEC2_TXD CODEC2_w/
MCLK_TXD
PSC2_1 I/O GPIO CAN1_RX AC97_2_SDATA_IN UART2_RXD UART2e_RXD CODEC2_RXD CODEC2_w/
MCLK_RXD
PSC2_2 I/O GPIO CAN2_TX AC97_2_SYNC UART2_RTS UART2e_RTS GPIO CODEC2_w/
MCLK_MCLK
PSC2_3 I/O GPIO CAN2_RX AC97_2_BITCLK UART2_CTS UART2e_CTS CODEC2_CLK CODEC2_w/
MCLK_CLK
PSC2_4 I/O GPIO_w/
WAKE_UP
GPIO_w/
WAKE_UP
AC97_2_RES GPIO_w/
WAKE_UP
UART2e_DCD CODEC2_FRAME
CODEC2_w/
MCLK_FRAME
GPIOCAN1/2CODEC2 AC972UART2(e)
1. CODEC usage leaves pin 3 open for simple GPIO.
2. CAN usage leaves pin 5 open for WakeUp GPIO.
3. CODEC plus additional GPIO from elsewhere can implement Soft Modem or RS-232 functionality.
4. AC97 usage is limited to PSC1 or PSC2.
5. MSCAN ports 1 and 2 can be configured here or on timer/I
2
C ports. They cannot be split.
(i.e., put CAN1 on PSC2 and CAN2 on the timer port).
5
5
PSC2_0 PSC2_1 PSC2_2 PSC2_3 PSC2_4
45 4
Pin Drivers and MUX Logic
6. CAN RX input supports WakeUp functionality.
Function
Port_conf
[25:27]
PSC_0 PSC_1 PSC_2 PSC_3 PSC_4
GPIO 000 GPIO GPIO GPIO GPIO GPIO_W/WAKE_UP
CAN1/2 001 CAN1_TX CAN1_RX CAN2_TX CAN2_RX GPIO_W/WAKE_UP
AC97_2 01X
AC97_2_SDATA_OUT AC97_2_SDATA_IN AC97_2_SYNC AC97_2_BITCLK AC97_2_RES
UART2 100 UART2_TXD UART2_RXD UART2_RTS UART2_CTS GPIO_W/WAKE_UP
UART2e 101 UART2e_TXD UART2e_RXD UART2e_RTS UART2e_CTS UART2e_DCD
CODEC2 110 CODEC2_TXD CODEC2_RXD GPIO CODEC2_CLK CODEC2_FRAME
CODEC2 w/
MCLK
111 CODEC2_w/
MCLK_TXD
CODEC2_w/
MCLK_RXD
CODEC2_w/
MCLK_MCLK
CODEC2_w/
MCLK_CLK
CODEC2_w/
MCLK_FRAME
Note:
