Pinout Tables
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 2-35
Table 2-12. PSC2 Functions by Pin
PIN / BALL NUMBER Function
Reset
Value
Description
Pin PSC2_0 Ball C09
GPIO hi - z GPIO
Simple General Purpose I/O
CAN1, CAN2 hi - z CAN1_TX
CAN Transmit
AC97_2 hi - z AC97_2_SDATA_OUT
AC97 Serial Data Out
UART2 hi - z UART2_TXD
Transmit Data
UART2e hi - z UART2e_TXD
Transmit Data
CODEC2 hi - z CODEC2_TXD
Transmit Data
CODEC2_w/MCLK hi - z CODEC2_w/MCLK_TXD
Transmit Data
Pin PSC2_1 Ball B09
GPIO hi - z GPIO
Simple General Purpose I/O
CAN_1, CAN_2 hi - z CAN1_RX
CAN Receive
AC97_2 hi - z AC97_2_SDATA_IN
AC97 Serial Data In
UART2 hi - z UART2_RXD
Receive Data
UART2e hi - z UART2e_RXD
Receive Data
CODEC2 hi - z CODEC2_RXD
Receive Data
Pin PSC2_2 Ball A09
GPIO hi - z GPIO
Simple General Purpose I/O
CAN1, CAN2 hi - z CAN2_TX
CAN Transmit
AC97_2 hi - z AC97_2_SYNC
AC97 Frame Sync
UART2 hi - z UART2_RTS
Ready To Send
UART2e hi - z UART2e_RTS
Ready To Send
CODEC2 hi - z GPIO
Simple General Purpose I/O
