MPC5200B Users Guide, Rev. 1

2-36 Freescale Semiconductor

Pinout Tables

Pin PSC2_3 Ball B08

GPIO hi - z GPIO

Simple General Purpose I/O

CAN1, CAN2 hi - z CAN2_RX

CAN Receive Data

AC97_2 hi - z AC97_2_BITCLK

AC97 Bit Clock

UART2 hi - z UART2_CTS

UART Clear To Send

UART2e hi - z UART2e_CTS

UARTe Clear To Send

CODEC2 hi - z CODEC2_CLK

CODEC Bit Clock

Pin PSC2_4 Ball A08

GPIO hi - z GPIO

Simple General Purpose I/O with WAKE UP

CAN1, CAN2 hi - z GPIO

Simple General Purpose I/O with WAKE UP

AC97_2 hi - z AC97_2_RES

AC97 Reset

UART2 hi - z GPIO

Simple General Purpose I/O with WAKE UP

UART2e hi - z UART2e_DCD

UARTe Carrier Detect

CODEC2 hi - z CODEC2_FRAME

CODEC Frame

Table 2-12. PSC2 Functions by Pin (continued)

PIN / BALL NUMBER Function

Reset

Value

Description
