ATA Register Interface
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 11-9
ATA FIFO is controlled by 32-bit registers. These registers are located at an offset from MBAR of 0x3a00. Register addresses are relative to
this offset. Therefore, the actual register address is: MBAR + 0x3A00 + register address
Hyperlinks to the ATA FIFO registers are provided below:
11.3.2.1 ATA Rx/Tx FIFO Data Word Register—MBAR + 0x3A3C
11.3.2.2 ATA Rx/Tx FIFO Status Register—MBAR + 0x3A40
• ATA Rx/Tx FIFO Data Word Register (0x3A3C) • ATA Rx/Tx FIFO Alarm Register (0x3A48)
• ATA Rx/Tx FIFO Status Register (0x3A40) • ATA Rx/Tx FIFO Read Pointer Register (0x3A4C)
• ATA Rx/Tx FIFO Control Register (0x3A44) • ATA Rx/Tx FIFO Write Pointer Register (0x3A50)
Table 11-13. ATA Rx/Tx FIFO Data Word Register
msb 012345678 9 1011121314 15
R FIFO_Data_Word
W
RESET:0 00000000 0 0 0 00 0 0
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 lsb
R FIFO_Data_Word
W
RESET:0 00000000 0 0 0 00 0 0
Bits Name Description
0:31 FIFO_Data_Word The FIFO data port. Reading from this location “pops” data from the FIFO, writing
“pushes” data into the FIFO. During normal operation the BestComm Controller
pushes data here.
Note: ONLY full long-word access is allowed. If all byte enables are not asserted
when accessing this location, a FIFO error flag is generated.
Table 11-14. ATA Rx/Tx FIFO Status Register
msb 012345678 9 1011121314 15
R
Reserved Err UF OF Full HI LO Emty
W
RESET:0 00000000 0 0 0 00 0 0
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 lsb
R
Reserved
W
RESET:0 00000000 0 0 0 00 0 0
Bits Name Description
0:8 — Reserved
9 Err Error—flag bit is essentially the logical "OR" of other flag bits and can be polled for detection
of any FIFO error. After clearing the offending condition, writing 1 to this bit clears flag.
