MPC5200B Users Guide, Rev. 1
2-66 Freescale Semiconductor
Pinout Tables
Table 2-24. PSC6 Pin Functions
Pin name Dir. GPIO UART6/ IrDA CODEC6 / IrDA
PSC6_0 I/O WAKE_UP UART6_RXD
IrDA_RX
CODEC6_RXD
Irda_RX
PSC6_1 I/O WAKE_UP UART6_CTS CODEC6_FRAME
PSC6_2 I/O SIMPLE GPIO UART6_TXD
IrDA_TX
CODEC6_TXD
IrDA_TX
PSC6_3 I/O SIMPLE GPIO UART6_RTS CODEC6_CLK/
IR_USB_CLK
Table 2-25. PSC6 Functions by Pin
PIN / BALL NUMBER Function
Reset
Value
Description
Pin PSC6_0 Ball B12
GPIO hi - z GPIO
Simple General Purpose I/O with WAKE UP
UART6 / IrDA hi - z UART6_RXD
Uart Receive Data
IrDA_RX IrDA Receive Data
CODEC6 / IrDA hi - z CODEC6_RXD
CODEC Receive Data
IrDA_RX IrDA Receive Data
Pin PSC6_1 Ball C11
GPIO hi - z GPIO
Simple General Purpose I/O with WAKE UP
UART6 hi - z UART6_CTS
Uart Clear To Send
CODEC6 hi - z CODEC6_FRAME
CODEC Frame Sync
Pin PSC6_2 Ball A12
GPIO hi - z GPIO
Simple General Purpose I/O
UART6 / IrDA hi - z UART6_TXD
Uart Transmit Data
IrDA_TX Irda Transmit Data
CODEC6 / IrDA hi - z CODEC6_TXD
CODEC Transmit Data
IrDA_TX Irda Transmit Data
Pin PSC6_3 Ball C13
GPIO hi - z GPIO
Simple General Purpose I/O
UART6 hi - z UART6_RTS
Uart Clear To Send
CODEC6 / IrDA hi - z CODEC6_CLK
IR_USB_CLK
