General Purpose I/O (GPIO)
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 7-23
PSC1_0 UART1/AC971/CODEC1 No No
PSC1_1 UART1/AC971/CODEC1 No No
PSC1_2 UART1/AC971 No No
PSC1_3 UART1/AC971/CODEC1 No No
PSC1_4 UART1/AC971/CODEC1 Yes Yes
PSC2_0 UART2/AC972/CODEC2/CAN1 No No
PSC2_1 UART2/AC972/CODEC2/CAN1 No No
PSC2_2 UART2/AC972/CAN2 No No
PSC2_3 UART2/AC972/CODEC2/CAN2 No No
GPIO_WKUP_1(PSC2_4) UART2/AC972/CODEC2 Yes Yes
GPIO_PSC3_0 USB2/CODEC3/UART3 No No
GPIO_PSC3_1 USB2/CODEC3/UART3 No No
GPIO_PSC3_2 USB2/CODEC3/UART3 No No
GPIO_PSC3_3 USB2/CODEC3/UART3 No No
GPIO_SINT_0(PSC3_4) USB2/UART3 Yes No
GPIO_SINT_1(PSC3_5) USB2 Yes No
GPIO_PSC3_6 USB2/SPI No No
GPIO_PSC3_7 USB2/SPI No No
GPIO_SINT_2(PSC3_8) USB2/SPI Yes No
GPIO_WKUP_2(PSC3_9) USB2/SPI Yes Yes
GPIO_USB_0 USB1 (OE) No No
GPIO_USB_1 USB1 (PORTPWR)/UART5 (TXD) No No
GPIO_USB_2 USB1 (SPEED)/UART5 (RTS) No No
GPIO_USB_3 USB1 (SUSPEND)/UART5 (CTS) No No
GPIO_SINT_3(USB) USB1 (OvrCrnt) Yes No
GPIO_ETHO_0(out only) Ethernet No No
GPIO_ETHO_1(out only) Ethernet/UART5 No No
GPIO_ETHO_2(out only) Ethernet/USB2/UART5 No No
GPIO_ETHO_3(out only) Ethernet/USB2/UART4 No No
GPIO_ETHO_4(out only) Ethernet/USB2/J1850 No No
GPIO_ETHO_5(out only) Ethernet/USB2/UART4 No No
GPIO_ETHO_6(out only) Ethernet/USB2 No No
GPIO_ETHO_7(out only) Ethernet/USB2 No No
GPIO_ETHI_0 Ethernet/UART5 No No
GPIO_ETHI_1 Ethernet/UART5 No No
Table 7-20. GPIO Pin List (continued)
GPIO PIN Alternate Functionality Interrupt WakeUp
