Freescale Semiconductor MPC5200B - Page 194

General Purpose I/O (GPIO)
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 7-35
Bit Name Description
0:1 — Reserved
2:3 IRDA Individual bits to control directionality of the pin as GPIO.
bit 2 controls GPIO_IRDA_1 (IR_USB_CLK pin)
bit 3 controls GPIO_IRDA_0 (IRDA_TX pin)
0 = Pin is Input (default)
1 = Pin is Output
4:7 ETHR Individual bits to control directionality of the pin as GPIO.
bit 4 controls GPIO_ETHI_3 (ETH_11 pin)
bit 5 controls GPIO_ETHI_2 (ETH_10 pin)
bit 6 controls GPIO_ETHI_1 (ETH_9 pin)
bit 7 controls GPIO_ETHI_0 (ETH_8 pin)
0 = Pin is Input (default)
1 = Pin is Output
8:11 — Reserved
12:15 USB Individual bits to control directionality of the pin as GPIO.
bit 12 controls GPIO_USB_3 (USB1_8 pin)
bit 13 controls GPIO_USB_2 (USB1_7 pin)
bit 14 controls GPIO_USB_1 (USB1_6 pin)
bit 15 controls GPIO_USB_0 (USB1_0 pin)
0 = Pin is Input (default)
1 = Pin is Output
16:17 — Reserved
18:23 PSC3 Individual bits to control directionality of the pin as GPIO.
bit 18 controls GPIO_ PSC3_5 (PSC3_7 pin)
bit 19 controls GPIO_ PSC3_4 (PSC3_6 pin)
bit 20 controls GPIO_ PSC3_3 (PSC3_3 pin)
bit 21 controls GPIO_ PSC3_2 (PSC3_2 pin)
bit 22 controls GPIO_ PSC3_1 (PSC3_1 pin)
bit 23 controls GPIO_ PSC3_0 (PSC3_0 pin)
0 = Pin is Input (default)
1 = Pin is Output
