Registers
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 10-19
10.3.2.6 Initiator Window 1 Base/Translation Address Register PCIIW1BTAR(RW) —MBAR +
0x0D74
16:23 Window 0
Translation
Address
For any translated bit (described above), the corresponding value here will be driven onto
the PCI address bus for the XL bus Window 0 address hit.
Note: The Window Translation operation can not be turned off. If a direct mapping from
XL Bus to PCI space is desired, program the same value to both the Window Base
Address Register and Window Translation Address Register.
24:31 Reserved Unused bits. Software should write zero to this register.
Table 1.
msb 012345678 9 1011121314 15
R Window 1 Base Address Window 1 Address Mask
W
RESET 0 00000000 0 0 0 00 0 0
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 lsb
R Window 1 Translation Address
Reserved
W
RESET 0 00000000 0 0 0 00 0 0
