MPC5200B Users Guide, Rev. 1
13-6 Freescale Semiconductor
BestComm DMA Registers—MBAR+0x1200
13.15.5
SDMA Interrupt Vector, PTD Control Register
—MBAR + 0x1210
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 lsb
R VariablePointer
W
RESET:0 00000000 0 0 0 00 0 0
Bit Name Description
0:31 variablePointer VariablePointer contains the starting address of the variable table for the currently
executing task.
Table 13-5. SDMA Interrupt Vector, PTD Control Register
msb 012345678 9 1011121314 15
R Vector A[7:6] INA[3:0] Vector B[7:6] INB[3:0]
W
RESET:0 00011110 0 0 0 11 1 1
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 lsb
RT/ITEA HE
Reserved PE
W
RESET:0 00000000 0 0 0 00 0 0
