BestComm DMA Registers—MBAR+0x1200
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 13-25
13.15.31 SDMA
Debug Module Control Register
—MBAR + 0x1278
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 lsb
RValue2
W
RESET:0 00000000 0 0 0 00 0 0
Bit Name Description
0:31 Value2 Debug Module Comparator 2 Value.
Table 13-32. SDMA Debug Module Control Register
msb 012345678 9 1011121314 15
RBlock Tasks
W
RESET:0 00000000 0 0 0 00 0 0
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 lsb
R AA B Comparator Type 1 Comparator Type 2 and/
or
EU breakpoints E I B
W
RESET:0 00000000 0 0 0 00 0 0
Bit Name Description
0:15 Block Tasks Specify for each of tasks 15-0, whether to block that task with detection of a breakpoint (bit
0 halts TASK 15, bit 1 halts TASK 14, etc)
0 Do not block task
1 Block the task
16 AA AutoArm—specifies whether or not the triggered bit dbgStatusReg[16] will be
automatically reset to 0 following the saving of context for a breakpoint. This bit is set to 0
at reset.
0 Triggered bit will not be automatically reset
1 Triggered bit will be automatically reset
17 B Breakpoint—This bit specifies whether or not to take a breakpoint. This bit is set to 0 at
reset.
0 Disable breakpoints
1 Enable breakpoints
18:20 Comparator
Typ e 1
Comparator 1 type—These bits specify the type of data that has been loaded into
comparator 1; refer to Ta ble 1 3- 33 for the bit encoding.
21:23 Comparators
Typ e 2
Comparator 2 type—These bits specify the type of data that has been loaded into
comparator 2; refer to Ta ble 1 3- 34 for the bit encoding.
24 and / or AND/OR—This specifies what type of operation is to be used with the comparators. This
bit is set to 0 at reset.
0 Indicates an OR’ing of the comparators
1 Indicates an AND’ing of the comparators
