FEC Memory Map and Registers
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 14-9
Table 14-8. MIB Counters
Address Mnemonic Description
200 RMON_T_DROP Count of Frames Not Correctly Counted
204 RMON_T_PACKETS RMON Tx Packet Count
208 RMON_T_BC_PKT RMON Tx Broadcast Packets
20C RMON_T_MC_PKT RMON Tx Multicast Packets
210 RMON_T_CRC_ALIGN RMON Tx Packets with CRC/Align error
214 RMON_T_UNDERSIZE RMON Tx Packets less than 64bytes, good CRC
218 RMON_T_OVERSIZE RMON Tx Packets greater than MAX_FL bytes, good CRC
21C RMON_T_FRAG RMON Tx Packets less than 64bytes, bad CRC
220 RMON_T_JAB RMONTxPackets greater than MAX_FL bytes, bad CRC
224 RMON_T_COL RMON Tx collision count
228 RMON_T_P64 RMON Tx 64Byte packets
22C RMON_T_P65TO127 RMON Tx 65 to 127Byte packets
230 RMON_T_P128TO255 RMON Tx 128 to 255Byte packets
234 RMON_T_P256TO511 RMON Tx 256 to 511Byte packets
238 RMON_T_P512TO1023 RMON Tx 512 to 1023Byte packets
23C RMON_T_P1024TO2047 RMON Tx 1024 to 2047Byte packets
240 RMON_T_P_GTE2048 RMON Tx packets with greater than 2048Bytes
244 RMON_T_OCTETS RMON Tx Octets
248 IEEE_T_DROP Count of Frames Not Counted Correctly
24C IEEE_T_FRAME_OK Frames Transmitted OK
250 IEEE_T_1COL Frames Transmitted with Single Collision
254 IEEE_T_MCOL Frames Transmitted with Multiple Collisions
258 IEEE_T_DEF Frames Transmitted after Deferral Delay
25c IEEE_T_LCOL Frames Transmitted with Late Collision
260 IEEE_T_EXCOL Frames Transmitted with Excessive Collisions
264 IEEE_T_MACERR Frames Transmitted with Tx FIFO Underrun
268 IEEE_T_CSERR Frames Transmitted with Carrier Sense Error
26C IEEE_T_SQE Frames Transmitted with SQE Error
270 T_FDXFC Flow Control Pause Frames Transmitted
274 IEEE_T_OCTETS_OK Octet Count for Frames Transmitted w/o Error
278–27C rsvd Reserved
280 RMON_R_DROP Count of frames Not Counted Correctly
284 RMON_R_PACKETS RMON Rx Packet Count
288 RMON_R_BC_PKT RMON Rx Broadcast Packets
28C RMON_R_MC_PKT RMON Rx Multicast Packets
