MPC5200B Users Guide, Rev. 1
2-10 Freescale Semiconductor
Pinout Tables
EXT_AD_4 V11 PSC6_0 B12
EXT_AD_5 W12 PSC6_2 A12
PSC6_3 C13 MEM_MBA_1 A17
PSC6_1 C11 MEM_MDQ_0 U20
IRQ0 P03 MEM_MDQ_1 U19
IRQ1 P01 MEM_MDQ_2 T20
IRQ2 P02 MEM_MDQ_3 T19
IRQ3 R01 MEM_MDQ_4 R20
JTAG_TCK B04 MEM_MDQ_5 R19
JTAG_TDI A03 MEM_MDQ_6 P20
JTAG_TDO A02 MEM_MDQ_7 P19
JTAG_TMS A04 MEM_MDQ_8 J19
JTAG_TRST B03 MEM_MDQ_9 J20
LP_ACK U14 MEM_MDQ_10 K19
LP_ALE V14 MEM_MDQ_11 K20
LP_OE D08 MEM_MDQ_12 L19
LP_RW W16 MEM_MDQ_13 L20
LP_TS Y13 MEM_MDQ_14 M19
MEM_CAS B19 MEM_MDQ_15 M20
MEM_CLK_EN F20 MEM_MDQ_16 E18
MEM_CS_0 B18 MEM_MDQ_17 F18
MEM_DQM_0 N19 MEM_MDQ_18 G17
MEM_DQM_1 H19 MEM_MDQ_19 G18
MEM_DQM_2 A20 MEM_MDQ_20 H18
MEM_DQM_3 L17 MEM_MDQ_21 J18
MEM_MA_0 C17 MEM_MDQ_22 J17
MEM_MA_1 A16 MEM_MDQ_23 K18
MEM_MA_2 B16 MEM_MDQ_24 M18
MEM_MA_3 C16 MEM_MDQ_25 N17
MEM_MA_4 B20 MEM_MDQ_26 N18
MEM_MA_5 C19 MEM_MDQ_27 P18
MEM_MA_6 C20 MEM_MDQ_28 R17
MEM_MA_7 D19 MEM_MDQ_29 R18
MEM_MA_8 D20 MEM_MDQ_30 T18
MEM_MA_9 E19 MEM_MDQ_31 U18
Table 2-2. Signals by Signal Name (continued)
Signal Name Ball/Pin Signal Name Ball/Pin
