Pinout Tables
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 2-19
Pin EXT_AD_24 Ball U03
LocalPlus Bus multiplexed mode
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A24
D0
D8
D24
hi - z
LocalPlus Address Bit 24
LocalPlus Data Bit 0
LocalPlus Data Bit 8
LocalPlus Data Bit 24
LocalPlus non-mux
16-bit addr/16-bit data
24-bit addr/8-bit data
D8
D0
hi - z
LocalPlus Data Bit 8
LocalPlus Data Bit 0
LFLASH D8 hi - z Large Flash Data Bit D8
MOST Graphics D24 hi - z MOST Graphics Data Bit D24
ATA ----- ----- -----
PCI
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A24
logic 0
logic 0
D24
hi - z
PCI Address Bit A24
logic 0
logic 0
PCI Data Bit 24
Pin EXT_AD_23 Ball W03
LocalPlus Bus multiplexed mode
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A23
logic 0
D7
D23
hi - z
Local Address Bit A23
logic 0
LocalPlus Data Bit 7
LocalPlus Data Bit 23
LocalPlus non-mux
16-bit addr/16-bit data
24-bit addr/8-bit data
D7
A23
hi - z
LocalPlus Data Bit 7
LocalPlus Address Bit A23
LFLASH D7 hi - z Large Flash Data Bit D7
MOST Graphics D23 hi - z MOST Graphics Data Bit D23
ATA ----- ----- -----
PCI
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A23
logic 0
logic 0
D23
hi - z
PCI Address Bit A23
logic 0
logic 0
PCI Data Bit D23
Pin EXT_AD_22 Ball V03
LocalPlus Bus multiplexed mode
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A22
logic 0
D6
D22
hi - z
LocalPlus Address Bit A22
logic 0
LocalPlus Data Bit 6
LocalPlus Data Bit D22
LocalPlus non-mux
16-bit addr/16-bit data
24-bit addr/8-bit data
D6
A22
hi - z
LocalPlus Data Bit D6
LocalPlus Address Bit A22
LFLASH D6 hi - z Large Flash Data Bit D6
MOST Graphics D22 hi - z MOST Graphics Data Bit D22
ATA ----- ----- -----
PCI
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A22
logic 0
logic 0
D22
hi - z
PCI Address Bit A22
logic 0
logic 0
PCI Data Bit D22
Table 2-5. LocalPlus Bus Address / Data Signals (continued)
PIN / BALL NUMBER Function
Reset
Value
Description
