MPC5200B Users Guide, Rev. 1
2-28 Freescale Semiconductor
Pinout Tables
Pin PCI_TRDY Ball W05
PCI PCI_TRDY logic 1 PCI_TRDY
PCI Target Ready
LFLASH A21 logic 1 Large Flash Address Bit A21
MOST Graphics A5 logic 1 MOST Graphics Address Bit A5
Pin PCI_IRDY Ball Y06
PCI PCI_IRDY logic 1 PCI Initiator (HOST) Ready
LFLASH A22 logic 1 Large Flash Address Bit A22
MOST Graphics A6 logic 1 MOST Graphics Address Bit A6
Pin PCI_STOP Ball V06
PCI PCI_STOP logic 1 PCI Transition Stop
LFLASH A23 logic 1 Large Flash Address Bit A23
MOST Graphics A7 logic 1 MOST Graphics Address Bit A7
Pin PCI_DEVSEL Ball W07
PCI PCI_DEVSEL logic 1 PCI Device Select
LFLASH A24 logic 1 Large Flash Address Bit A24
MOST Graphics A8 logic 1 MOST Graphics Address Bit A8
Pin PCI_FRAME Ball V05
PCI PCI_FRAME logic 1 PCI Frame Start
LFLASH A25 logic 1 Large Flash Address Bit A25
MOST Graphics A9 logic 1 MOST Graphics Address Bit A9
Pin PCI_SERR Ball W08
PCI PCI_SERR logic 1 PCI System Error (open drain)
MOST Graphics A10 logic 1 MOST Graphics Address Bit A10
Pin PCI_PERR Ball Y07
PCI PCI_SERR logic 1 PCI Parity Error
MOST Graphics A11 logic 1 MOST Graphics Address Bit A11
Pin PCI_IDSEL Ball U02
PCI PCI_IDSEL logic 1 PCI Initial Device Select
MOST Graphics A12 logic 1 MOST Graphics Address Bit A12
Pin PCI_REQ Ball U01
PCI PCI_REQ logic 1 PCI Bus Request
MOST Graphics A13 logic 1 MOST Graphics Address Bit A13
Pin PCI_GNT Ball R04
PCI PCI_GNT logic 1 PCI Bus Grant
MOST Graphics A14 logic 1 MOST Graphics Address Bit A14
Pin PCI_CLOCK Ball T01
PCI PCI_CLOCK clk PCI Clock
Table 2-6. PCI Dedicated Signals (continued)
PIN / BALL NUMBER Function
Reset
Value
Description
