MPC5200B Users Guide, Rev. 1
2-32 Freescale Semiconductor
Pinout Tables
Table 2-10. PSC1 Functions by Pin
PIN / BALL NUMBER Function
Reset
Value
Description
Pin PSC1_0 Ball B11
GPIO hi - z GPIO
Simple General Purpose I/O
AC97_1 hi - z AC97_1_SDATA_OUT
AC97 Serial Data Out
UART1 hi - z UART1_TXD
Transmit Data
UART1e hi - z UART1e_TXD
Transmit Data
CODEC1 hi - z CODEC1_TXD
Transmit Data
CODEC1_w/MCLK hi - z CODEC1_w/MCLK_TXD
Transmit Data
Pin PSC1_1 Ball A11
GPIO hi - z GPIO
Simple General Purpose I/O
AC97_1 hi - z AC97_1_SDATA_IN
AC97 Serial Data In
UART1 hi - z UART1_RXD
Receive Data
UART1e hi - z UART1e_RXD
Receive Data
CODEC1 hi - z CODEC1_RXD
Receive Data
CODEC1_w/MCLK hi - z CODEC1_w/MCLK_RXD
Receive Data
Pin PSC1_2 Ball C10
GPIO hi - z GPIO
Simple General Purpose I/O
AC97_1 hi - z AC97_1_SYNC
AC97 Frame Sync
UART1 hi - z UART1_RTS
Ready To Send
UART1e hi - z UART1e_RTS
Ready To Send
CODEC1 hi - z GPIO
Simple General Purpose I/O
CODEC1_w/MCLK hi - z CODEC1_w/MCLK _MCLK
