Pinout Tables
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 2-39
Pin PSC3_1 Ball B07
GPIO hi - z GPIO
Simple General Purpose I/O
USB2 hi - z USB2_TXN
USB Transmit Negative
UART3 hi - z UART3_RXD
Uart Receive Data
UART3e hi - z UART3e_RXD
Uart Receive Data
CODEC3 hi - z CODEC3_RXD
CODEC Receive Data
CODEC3_w/MCLK hi - z CODEC3_w/MCLK_RXD
CODEC Receive Data
SPI hi - z GPIO
Simple General Purpose I/O
UART3, SPI hi - z UART3_RXD
Uart Receive Data
UART3e,SPI hi - z UART3e_RXD
Uart Receive Data
CODEC3, SPI hi - z CODEC3_RXD
CODEC Receive Data
Pin PSC3_2 Ball A07
GPIO hi - z GPIO
Simple General Purpose I/O
USB2 hi - z USB2_TXP
USB Transmit Positive
UART3 hi - z UART3_RTS
Uart Ready To Send
UART3e hi - z UART3e_RTS
Uart Ready To Send
CODEC3 hi - z CODEC3_CLK
CODEC Bit Clock
CODEC3_w/MCLK hi - z CODEC3_w/MCLK_CLK
CODEC Bit Clock
SPI hi - z GPIO
Simple General Purpose I/O
UART3, SPI hi - z UART3_RTS
Uart Ready to Send
UART3e, SPI hi - z UART3_RTS
Uart Ready To Send
CODEC3, SPI hi - z CODEC3_CLK
CODEC Clock
Table 2-15. PSC3 Functions by Pin (continued)
PIN / BALL NUMBER Function
Reset
Value
Description
