10.4.8 MLD Snooping
10.4.8.1 Show Commands
10.4.8.1.1 show ipv6 mld snooping
The user can go to the CLI Privilege Mode to get all of mld snooping information, use the show ip mld
snooping Privilege command.
Syntax
show ipv6 mld snooping [<slot/port>|<vlan-id>]
Default Setting
None
Command Mode
Privileged Exec, User Exec
Display Message
When the optional arguments <slot/port> or <vlanid> are not used, the command displays the
following information:
Admin Mode: Indicates whether or not MLD Snooping is active on the switch
Interfaces Enabled for MLD Snooping: Interfaces on which MLD Snooping is enabled.
MLD Control Frame Count: Displays the number of MLD Control frames that are processed by
the CPU
VLANs Enabled for MLD Snooping: VLANs on which MLD Snooping is enabled
When you specify the <slot/port> values, the following information displays:
MLD Snooping Admin Mode: Indicates whether MLD Snooping is active on the interface.
Fast Leave Mode: Indicates whether MLD Snooping Fast Leave is active on the interface.
Group Membership Interval: Shows the amount of time in seconds that a switch will wait for a
report from a particular group on a particular interface, which is participating on the interface,
before deleting the interface from the entry. This value may be configured.
Max Response Time: Interface on which MLD Snooping is enabled
Multicast Router Present Expiration Time: Displays the amount of time to wait before
removing an interface that is participating on the interface from the list of interfaces with multicast
routers attached. The interface is removed if a query is not received. This value may be
configured.
When you specify a value for <vlanid>, the following information appears:
VLAN ID: VLAN ID
MLD Snooping Admin Mode: Indicates whether MLD Snooping is active on the VLAN.
Fast Leave Mode: Indicates whether MLD Snooping Fast Leave is active on the VLAN.
