7.2 Basic information
The HDD or SSD and the installation frame together make up the HDD module
or SSD module.
The server is shipped with one of the following HDD or SSD subsystems:
–
3.5-inch HDD subsystem
–
2.5-inch HDD/SSD subsystem
3.5-inch HDD subsystem
Up to four 3.5-inch SAS/SA
T
A HDD modules can be installed. The HDD
module is connected to the HDD backplane wirelessly. This allows HDD
modules to be plugged in or pulled out easily.
Hybrid configurations of SAS and SATA HDD modules are supported in
combination with an optional HDD controller.
For information on RAID controllers controlling the HDD modules, see
"Expansion cards and backup units" on page 179.
2.5-inch HDD/SSD subsystem
–
Up to four (RX1330 M5S) or up to eight 2.5-inch HDD / SSD / PCIe SSD
modules can be installed depending on configuration.
The HDD / SSD / PCIe SSD modules are connected to the HDD backplane
wirelessly. This allows HDD / SSD / PCIe SSD modules to be plugged in or
pulled out easily
. If the HDD / SSD / PCIe SSD modules are controlled by a
RAID controller, defective HDD / SSD / PCIe SSD modules can also be
replaced during operation.
–
Up to 10 2.5-inch HDD/SSD modules can be installed depending on
configuration.
The HDD/SSD modules are connected to the HDD backplane wirelessly.
This allows HDD/SSD modules to be plugged in or pulled out easily.
If the HDD/SSD modules are controlled by a RAID controller, defective
HDD/SSD modules can be replaced during operation.
Hard disk drive (HDD) / solid state disk (SSD)
120 Upgrade and Maintenance Manual RX1330 M5
