Remove the two screws (see circles).
▶
Remove the front VGA cable from the cable clamp (A).
▶
Pull the front VGA connector out of the recess in the front VGA module.
▶
Thread the front VGA cable through the opening and remove it.
Installing the new front VGA
▶
Install the front VGA, see "Installing the front VGA" on page 266.
▶
Install the front VGA module, see "Installing the front VGA module" on
page
267
.
▶
Connect the front VGA cable, see "Connecting the front VGA cable" on
page 268.
Concluding steps
▶
"Installing the air duct" on page 66.
▶
"Reassembling" on page 53.
▶
"Connecting the power cord" on page 57.
▶
"Switching on the server" on page 60.
▶
If applicable, "Installing the front cover with lock" on page 61.
13.4.4 Installing the front VGA
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: – flat screw driver (for break out)
–
hexagon screw driver 5 mm
Front panel
270 Upgrade and Maintenance Manual RX1330 M5

Fujitsu PRIMERGY RX1330 M5 Specifications

General

Processor Sockets	1
Memory	Up to 128 GB
Memory Type	DDR4
Form Factor	1U rack server
Memory Slots	4 DIMM slots
Storage	Up to 4x 3.5" or 8x 2.5" drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	2x 1GbE LAN ports
Power Supply	800W
