Connect the power cable to the power distribution board and to connector
"PWR1" on the system board.
▶
Install all PSUs, see "Installing a hot-plug PSU" on page 102.
Concluding steps
▶
"Reassembling" on page
53
▶
"Connecting the power cord" on page 57.
▶
"Switching on the server" on page 60.
▶
If applicable, "Installing the front cover with lock" on page 61.
▶
"Resuming BitLocker functionality" on page 86.
6.4.5 Replacing the power distribution board
(RX1330 M5S)
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page 43
.
▶
"Suspending BitLocker functionality" on page 69.
▶
If applicable, "Removing the front cover with lock" on page 45.
▶
"Shutting down the server" on page 46.
▶
"Disconnecting the power cord" on page 47.
▶
"Getting access to the component" on page 49
Removing the defective power distribution board
▶
Remove all PSUs, see "Removing a hot-plug PSU" on page 105.
Power supply unit (PSU)
RX1330 M5 Upgrade and Maintenance Manual 113
