4.4 Disconnecting the power cord
4.4.1 Disconnecting the power cord
Standard power supply
Figure 4: Unlocking the cable tie of a standard PSU
▶
Pull out on the locking lever on the cable tie (1) and loosen the loop (2).
▶
Disconnect the power cord from the PSU and remove it from the cable tie.
Basic hardware procedures
RX1330 M5 Upgrade and Maintenance Manual 47
