Fujitsu PRIMERGY RX1330 M5 User Manual

4 Basic hardware procedures
4.1 Using diagnostic information
4.1.1
Proceeding
Use the Fujitsu ServerView Suite management software to plan the upgrade or
replacement of hardware components.
It is recommended to prepare local maintenance tasks using remote
diagnostics procedures, see the "ServerView Suite Local Service Concept
(LSC)" manual.
In Japan remote diagnostics procedures are not used.
Please contact your local Fujitsu customer service partner for details on the
service concept and on how to order expansion kits or spare parts.
4.1.2 Locating the defective server
Use the ID indicator for easy identification of the server
, especially when
working in a datacenter environment or a server room:
▶
Press the ID button on the front panel, use the iRMC S6 web interface or
Infrastructure Manager to switch on the system identification LEDs.
For more information, see the "ServerView Suite Local Service
Concept (LSC)" manual, the iRMC user guides or the Infrastructure
Manager documentation.
▶
Remember to switch off the ID indicator after the maintenance task has
been concluded successfully.
Using the Infrastructure Manager
▶
To toggle the ID indicator from the Infrastructure Manager, select a node
from the Node List screen and operate the ID indicator from the Action
button.
RX1330 M5 Upgrade and Maintenance Manual 43

Fujitsu PRIMERGY RX1330 M5 Specifications

General

Processor Sockets	1
Memory	Up to 128 GB
Memory Type	DDR4
Form Factor	1U rack server
Memory Slots	4 DIMM slots
Storage	Up to 4x 3.5" or 8x 2.5" drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	2x 1GbE LAN ports
Power Supply	800W
