Fujitsu PRIMERGY RX1330 M5 User Manual

Figure 7: Removing the server from the rack
▶
Press on the locking bars on both rack rails (1).
▶
Lift the server out of the rack rails (2) and place it on an even surface.
4.5.4
Removing the top cover
The RX1330 M5 is offered with different depth. In this manual the
RX1330 M5 with short depth is named RX1330 M5S.
Figure 8: Removing the top cover
Basic hardware procedures
52 Upgrade and Maintenance Manual RX1330 M5

Fujitsu PRIMERGY RX1330 M5 Specifications

General

Processor Sockets	1
Memory	Up to 128 GB
Memory Type	DDR4
Form Factor	1U rack server
Memory Slots	4 DIMM slots
Storage	Up to 4x 3.5" or 8x 2.5" drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	2x 1GbE LAN ports
Power Supply	800W
