Concluding steps
▶
"Connecting the power cord" on page 57.
▶
Only when replacing a PSU in a non-redundant configuration: "Switching on
the server" on page
60.
▶
"Performing a fan test" on page 94.
Performing a fan test is not needed if the hot-plug PSU is actively
replaced. iRMC runs automatically.
6.4.4
Replacing the power distribution board
(RX1330 M5)
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page 43
.
▶
"Suspending BitLocker functionality" on page 69.
▶
If applicable, "Removing the front cover with lock" on page 45.
▶
"Shutting down the server" on page 46.
▶
"Disconnecting the power cord" on page 47.
▶
"Getting access to the component" on page 49
Removing the defective power distribution board
▶
Remove all PSUs, see "Removing a hot-plug PSU" on page 105.
Power supply unit (PSU)
108 Upgrade and Maintenance Manual RX1330 M5

Fujitsu PRIMERGY RX1330 M5 Specifications

General

Processor Sockets	1
Memory	Up to 128 GB
Memory Type	DDR4
Form Factor	1U rack server
Memory Slots	4 DIMM slots
Storage	Up to 4x 3.5" or 8x 2.5" drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	2x 1GbE LAN ports
Power Supply	800W
