Note for servers using CMA (Cable Management Arm)
Regarding of removing PSUs, additional tasks are needed, due to an
interference between CMA and the PSUs.
▶
Push the lock spring inward to unlock the CMA bracket, see Figure 35.
▶
Remove the CMA.
▶
Hold the CMA including cables in the one hand.
▶
Remove the PSU (see Figure 36) and install the new PSU carefully
.
Note for PSU 1:
Remove the PSU 1 carefully while lifting PSU 1 and bringing PSU 1
to the right, in order to avoid interference.
▶
Mount the complete assembly (CMA bracket and the CMA) again into the
rail.
Preliminary steps
▶
"Locating the defective server" on page
43
.
▶
Check which PSU is defective.
PSU is defective when the PSU status indicator lights orange. For more
information, see "Indicator on hot-plug PSU" on page 358.
▶
Only when replacing a PSU in a non-redundant configuration: "Shutting
down the server" on page 46.
▶
Remove the power cord from the defective PSU, see "Disconnecting the
power cord" on page 47.
Removing the defective hot-plug PSU
▶
Remove the PSU, see "Removing a hot-plug PSU" on page 105.
Installing the new hot-plug PSU
▶
Install the PSU, see "Installing a hot-plug PSU" on page 102.
Power supply unit (PSU)
RX1330 M5 Upgrade and Maintenance Manual 107

Fujitsu PRIMERGY RX1330 M5 Specifications

General

Processor Sockets	1
Memory	Up to 128 GB
Memory Type	DDR4
Form Factor	1U rack server
Memory Slots	4 DIMM slots
Storage	Up to 4x 3.5" or 8x 2.5" drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	2x 1GbE LAN ports
Power Supply	800W
