4.6.4 Sliding the server into the rack
Figure 13: Sliding the server into the rack
▶
Release the locking mechanism of both rails (1).
▶
Push the server as far as it will go into the rack (2) until the quick-release
lever on the left side engages (3).
CAUTION
▶
Be careful with your fingers. You can pinch them when the quick
release levers change to the release position.
▶
Connect all cables except the power cord to the server rear
.
4.7
Connecting the power cord
4.7.1 Connecting the power cord (standard PSU)
CAUTION
The server automatically adjusts to a mains voltage in the range from
100 V - 240 V
.
▶
You may only operate the server if its rated voltage range
corresponds to the local mains voltage.
Basic hardware procedures
RX1330 M5 Upgrade and Maintenance Manual 57
